USED LOVOL FR150-7 EXCAVATOR

I. Basic Parameters

• Equipment Model: Foton Lovol FR150-7
• Model Abbreviation: FR150-7
• Tonnage (tons): 15
• Operating Weight (kg): 14,050
• Bucket Capacity (m³): 0.52
• Origin: Qingdao, Shandong
• Power Source: Traditional Power
• Manufacturer: Domestic (Made in China)
• Bucket Type: Backhoe

II. Engine Parameters

• Engine Model: Isuzu BB-4BG1TRP
• Rated Power (kW/rpm): 73.5/2,200
• Maximum Torque (N·m/rpm): 337.5±20/1,600
• Displacement (L): 3.922
• Number of Cylinders: 4
• Cylinder Bore × Stroke (mm): 105×125
• Cooling Method: Water-cooled
• Operating Mode: Direct injection, overhead valves, with turbocharging

III. Performance Parameters

• Slewing Speed (rpm): 13
• Traveling Speed (km/h): 5.2/3.3 (High/Low) or 5.9/3.7 (High/Low)
• Climbing Ability (%): 35°
• Ground Pressure (Kpa): 41
• Bucket Digging Force (kN): 94.9
• Arm Digging Force (kN): 84.7
• Maximum Tractive Force (kN): 110

IV. Hydraulic System Parameters

• Main Pump Type: Swashplate Piston Pump
• Maximum Flow Rate of Main Pump (L/min): 266

V. Main Dimensions Parameters

• Boom Length (mm): 4,600
• Arm Length (mm): 2,500
• Overall Length for Transportation (mm): 7,746
• Overall Width for Transportation (mm): 2,520
• Overall Height for Transportation (mm): 2,830
• Track Plate Width (mm): 500

VI. Operating Range Parameters

• Maximum Digging Radius (mm): 8,300
• Maximum Digging Depth (mm): 5,435
• Maximum Digging Height (mm): 8,610
• Maximum Dumping Height (mm): 6,130
