| Model Name |
JAC Refine M5 2016 2.0T Gasoline Manual Official Edition / Automatic Official Edition |
| Manufacturer |
JAC Motors |
| Vehicle Class |
Large MPV |
| Energy Type |
Gasoline |
| Body Structure |
5-door 7-seat MPV |
| Manufacturer's Guide Price (10,000 CNY) |
Manual 15.25; Automatic 16.25 |
| Launch Time |
2016-04-25 |
| Length×Width×Height (mm) |
5100×1840×1970 |
| Wheelbase (mm) |
3080 |
| Curb Weight (kg) |
2155 |
| Drive Type |
Front-engine, Rear-wheel Drive |
| Transmission Type |
6-speed Manual Transmission (MT)/5-speed Automatic Transmission (AT) |
| Engine Model |
HFC4GA3-1D |
| Engine Type |
2.0T Inline 4-cylinder Turbocharged Gasoline Engine |
| Displacement (mL) |
1997 |
| Maximum Power (kW) |
130 (177Ps) |
| Maximum Power Speed (rpm) |
5400 |
| Maximum Torque (N·m) |
260 |
| Maximum Torque Speed (rpm) |
2000-4000 |
| Fuel Grade |
92# Gasoline |
| Fuel Supply System |
Multi-point Electronic Injection |
| Emission Standard |
National IV (National V) |
| Maximum Speed (km/h) |
165 |
| Front Suspension Type |
Double Wishbone Independent Suspension |
| Rear Suspension Type |
Solid Axle Dependent Suspension |
| Body Structure |
Load-bearing Type |
| Brake Type |
Front Ventilated Disc/Rear Disc |
| Parking Brake |
Mechanical Handbrake |
| Tire Specification |
225/60 R17 |
| Fuel Tank Capacity (L) |
80 |
